Description
The Westfalia SDA 360 sanitary decanter centrifuge is designed for efficient separation processes in various applications. This specific unit, with Serial Number 1535025, features a maximum bowl speed of 4000 RPM and a centrifugal force of 3180 x G, making it suitable for a range of industrial uses. The effluent is discharged under pressure, which enhances the efficiency of the separation process. The decanter is equipped with a 110mm single lead polished conveyor, ensuring smooth material handling during operation. It is powered by a robust 30 HP motor, capable of operating at 230/460 volts, 3-phase, 60 Hz, with a speed of 1785 RPM. This unit is in good condition, although it is missing the cyclo gear and both bowl heads, which may need to be addressed for full functionality.
Engineers and purchasing managers will find the Westfalia SDA 360 to be a reliable choice for applications requiring solid-liquid separation. The design of this centrifuge allows for easy maintenance and operation, making it a practical option for facilities looking to optimize their separation processes. The use of 316 stainless steel in its construction provides durability and resistance to corrosion, which is essential in sanitary applications. The centrifuge's design is focused on achieving effective separation while maintaining the integrity of the materials being processed.
Primary Use
Used for separating solids from liquids in various industrial processes.
Technical Specifications
- Bowl Speed: 4000 RPM
- Centrifugal Force: 3180 x G
- Conveyor Diameter: 110 mm
- Motor Power: 30 HP
- Voltage: 230/460 V
- Phase: 3
- Frequency: 60 Hz
- Motor Speed: 1785 RPM
Key Features
- Bowl Construction
- Conveyor Design
- Motor Specifications
- Separation Efficiency
- Maintenance Accessibility
Applications
- Food processing
- Beverage clarification
- Pharmaceutical manufacturing
- Chemical processing
- Wastewater treatment
Product Details
The Westfalia SDA 360 is constructed from 316 stainless steel, providing resistance to corrosion and ensuring compliance with sanitary standards. Its design includes a polished conveyor for efficient material handling and ease of cleaning.
