Westfalia KNA 3-06-076 quark separator, 316SS.

Max bowl speed 8520 RPM. Input up to 700 LPM coagulated skim milk. Output up to 230 kg/h quark (17% dry matter). 4 KW motor 380/3/50, bowl has 8 nozzles: 2x 0.3, 2x 0.4 and 4x blind. Clean-in-place, m

VIEW DETAILS

Westfalia NA 7-06-076 clarifier centrifuge, 316SS.

Max bowl speed 8510 RPM, rated @ 5000 LPH. Combination desludger/nozzle bowl, liquid discharged under pressure. 7.5 HP motor 230/460/3/60/1800 RPM with piping, valves, gauges, turbidity meter, timing

VIEW DETAILS

Westfalia KDA 16-02-177 quark separator, 316SS.

Max bowl speed 5500 RPM, rated @ 4000-5000 LPH input, 900-1000 KGPH output. 30 KW motor 380/3/50/1440 RPM, base plate and tools. Very good condition. FCA Europe.

VIEW DETAILS

Westfalia KNA 14-02-076 cream cheese separator, 316SS.

Max bowl speed 7500 RPM, rated @ 1500 LPH, 7.5 KW motor 380/3/50/1450 RPM, counter-pressure, control bypass and water valves, manometer on whey, sludge tank, base frame and tools. No control panel. Ex

VIEW DETAILS

Westfalia SIH 10007 CIP quark separator, 316SS.

Max bowl speed 5500 RPM, rated @ 1500 kg/hr, 3300 PPH. Painted frame with SS cover and lower casing. Light phase discharged under pressure via paring disc, heavy phase (quark) discharged by gravity th

VIEW DETAILS

Westfalia SIH 10007 CIP quark separator, 316SS.

Max bowl speed 5500 RPM, rated @ 1500 kg/hr, 3300 PPH. 15 KW motor 480/3/60 and 0.75 KW scraper blade motor, tools and control panel. Very good condition. Equivalent to: KDA 18-02-177.

VIEW DETAILS

Westfalia KDA 18-02-177 CIP quark separator, 316SS.

Max bowl speed 5350 RPM, rated @ 1500 kg/hr, 3300 PPH, SS motor and base. 20 KW motor 380/3/50/2905 RPM, 0.75 KW scraper blade motor, scraper, manometer, counter pressure valve, flow meter, solids col

VIEW DETAILS

Westfalia HDA 30-06-076 nozzle centrifuge, 316SS.

Max bowl speed 7510 RPM, 8265 x G, rated @ 6000 LPH, 18.5 KW motor 400/690/3/50/1465 RPM, disassembled with spanner wrench. 2000 vintage. Prior use: Yeast. Very good condition. FCA Europe.

VIEW DETAILS

Westfalia KDA 30-02-177 quark separator, 316SS.

Max bowl speed 5350 RPM, rated @ 10,000 LPH input, 2100 KPH output, 20 KW motor 460/3/60/1770 RPM and tools. No control panel. Excellent condition. Located in UK.

VIEW DETAILS

Westfalia HDA 30-06-006 nozzle centrifuge, 316SS.

Max bowl speed 7480 RPM, 8265 x G, rated @ 6000 LPH, sanitary yeast design, 11 KW motor 460/3/50/1750 RPM, 3 sets of nozzles and top piping. No tools or controls. 1991 vintage. Very good condition.

VIEW DETAILS

Westfalia KDA 30-02-177 quark separator, 316SS.

Max bowl speed 5350 RPM, rated @ 10,000 LPH input, 2500 KPH output, 20 KW motor 380/3/50/2910 RPM. No sludge tank, back-pressure valve, base frame, tools or controls. 1980 vintage. Very good condition

VIEW DETAILS

Westfalia CNB 45-01-076 bacteria separator, 316SS.

Max bowl speed 6450 RPM, rated 5,000 LPH. 15 KW motor 380/3/50/1450 RPM, fluid clutch, valves and base plate. No tools or controls. 1983 vintage. Very good condition. FCA Europe.

VIEW DETAILS

Westfalia CNB 45-01-076 bacteria separator, 316SS.

Max bowl speed 6450 RPM, rated 5,000 LPH. 15 KW motor 380/3/50/1450 RPM, fluid clutch, water valves and tools. No control panel. 1986 vintage. Excellent condition. FCA Europe.

VIEW DETAILS

Westfalia HDB 50-06-006 nozzle centrifuge, 316SS.

Max bowl speed 5920 RPM, rated @ 50 GPM, 22 KW motor 220/380/3/50/60/1460 RPM. Missing centripetal pump assembly. 1988 vintage. Excellent condition.

VIEW DETAILS

(2) Westfalia SIG 15007 nozzle centrifuges, 316 SS.

Complete with 60 HP motor. Prior use: Starch/gluten/dextrose separation. Equivalent to: DA 100-01-117. Good rebuildable condition.


Westfalia DA 100-06-117 nozzle centrifuge, 316SS.

Max bowl speed 3340 RPM, rated @ 18,000 LPH, concentrator without recycle feature, 70 KW motor 380/3/50/2950 RPM. No tools or controls. 1989 vintage. Very good condition. FCA Europe. ***MISSING DISC

VIEW DETAILS

Westfalia StK 15007 nozzle centrifuge, 316SS.

Max bowl speed 3200 RPM, rated @ 18,000 LPH, concentrator without recycle feature, 90 KW motor 380/3/50/2955 RPM. No tools or controls. To be reconditioned to "as new" with 12 month full mechanical wa

VIEW DETAILS

(5) Westfalia DA 100-06-117 nozzle centrifuges, 316SS.

Max bowl speed 3340 RPM, rated @ 18,000 LPH, concentrator without recycle feature, 70 KW motor 380/3/50 and tools 1979 and 1989 vintage. Very good condition. Located in Europe.

VIEW DETAILS

(2) Westfalia DA 100-76-117 nozzle centrifuges, 316SS.

Max bowl speed 3340 RPM, rated @ 18,000 LPH, concentrator with recycle feature, 70 KW motor 380/3/50 and tools. 1991 vintage. Very good condition. Located in Europe.

VIEW DETAILS

(2) Westfalia SDA 130-76-107 nozzle centrifuges, 316SS.

Max bowl speed 4500 RPM, rated @ 250 CMPH, liquid phase discharged under pressure, concentrated starch discharged into solids vessel; one with wash water feature, one without, 132 KW motor 380/3/50/30
