Rosler Z 800 HA Turbo-Floc separator skid, manual clean.

Max bowl speed 2930 RPM, 1750 x G, rated @ 1200 LPH, 11 L (2.9 G) sludge volume, 28 kg max load. 5 KW motor 460/3/60, 365mm (14.4") diameter aluminum bowl with plastic liner for easy sludge removal, special guiding cone for optimum separation results, automatic discharge of residual liquid from the drum, lid lock, 250 L dirty water tank with pre-screen, level indicator by float switch with “full” alarm, stirrer and angled tank bottom for easy emptying, feeding of the dirty process water by adjustable compressed air diaphragm pump (pulse controlled) and Siemens PLC controller, unitized on a skid. 2010 vintage. Excellent condition; still running. Current use: Ceramic polishing.

Note: We are selling our whole turn-key ceramic polishing setup. We have 1 large ceramic polisher that can polish up to 32 inch wheels, 2 ceramic polishers that can polish up to 28 inch wheels, this centrifuge and a large tumbler that can polish up to 20 inch wheels available.

The Rosler Z 800 HA Turbo-Floc separator skid, manual clean, is engineered for high efficiency and optimal performance in the demanding environment of ceramic polishing. With a maximum bowl speed of 2930 RPM and a centrifugal force of 1750 x G, this separator is capable of handling a rated throughput of 1200 liters per hour. The design incorporates a 365mm (14.4") diameter aluminum bowl lined with plastic, facilitating easy sludge removal and ensuring that maintenance is straightforward and efficient. The unit's special guiding cone is a critical feature, enhancing the separation process to achieve superior results in the removal of contaminants from the dirty process water. This is particularly beneficial in ceramic polishing applications, where the quality of the final product is paramount.

The Rosler Z 800 HA Turbo-Floc separator skid is equipped with a robust 5 KW motor operating at 460/3/60, providing the necessary power to maintain high operational efficiency. The system includes a 250-liter dirty water tank with a pre-screen, which is essential for filtering out larger particles before they reach the separator. The level indicator, controlled by a float switch, features a 'full' alarm to prevent overflow and ensure continuous operation. Additionally, the stirrer and angled tank bottom design promote easy emptying of the tank, minimizing downtime. The adjustable compressed air diaphragm pump allows for precise feeding of dirty process water, while the Siemens PLC controller enhances operational control and monitoring. This unitized skid design not only simplifies installation but also ensures that the entire setup is compact and easy to maneuver within your facility.

In summary, the Rosler Z 800 HA Turbo-Floc separator skid, manual clean, is an invaluable asset for any ceramic polishing operation. Its combination of high-speed performance, durable construction, and user-friendly features make it an ideal choice for businesses looking to enhance their polishing capabilities. With the added benefit of being part of a complete turn-key ceramic polishing setup, including large polishers and a tumbler, this separator is ready to contribute to your production efficiency and product quality.
