Description:
Max bowl speed 2600 RPM, 2004 Gs, co-current design. Bowl ID: 531 x 2298mm = 20.9 x 90.5". Rated @ 8-25 m3/hr (110 GPM max), 800 kg max dry solids STC tiles on feed zone, conveyor and cake discharge ports. 30 KW ABB main drive 440/3/60/1750 RPM, 7.5 KW backdrive both with VFDs, feed tube, guards, lube system and control panel. Prior use: Circuit board mfg. 2010, 2011 vintage. Excellent condition.
The (6) Noxon DC20EL-HS-CC decanters, epoxy-coated CS, are engineered for high-efficiency separation processes, making them an ideal choice for industries requiring reliable and robust equipment. With a maximum bowl speed of 2600 RPM and generating forces up to 2004 Gs, these decanters excel in their ability to handle a wide range of materials. The co-current design enhances the separation process, ensuring optimal performance and minimal downtime. The bowl dimensions of 531 x 2298 mm (20.9 x 90.5 inches) provide ample capacity for various applications, while the rated throughput of 8-25 m³/hr (up to 110 GPM) allows for significant operational flexibility. This versatility is further complemented by the capability to manage up to 800 kg of dry solids in the feed zone, conveyor, and cake discharge ports, making these decanters suitable for demanding industrial environments.
Equipped with a powerful 30 KW ABB main drive operating at 440/3/60/1750 RPM, along with a 7.5 KW backdrive, both featuring variable frequency drives (VFDs), the (6) Noxon DC20EL-HS-CC decanters ensure precise control over the separation process. The inclusion of a feed tube, safety guards, a lubrication system, and an integrated control panel enhances operational safety and efficiency. These features not only streamline the setup and operation but also facilitate maintenance, ensuring that the decanters remain in excellent working condition. Previously utilized in circuit board manufacturing, these decanters from the 2010 and 2011 vintage have been well-maintained and are in excellent condition, ready to meet the rigorous demands of modern industrial applications.
Key Features:
High-Speed Performance, Robust Construction, Versatile Applications, Efficient Maintenance, Integrated Safety Features
